AHRS

Inertial Labs is a designer, developer and manufacturer of position and orientation tracking systems. They produce a variety of the inertial sensors that are industry’s smallest at lowest cost.Applications:
  • Human Motion Tracking
  • Real-time Immersive Training
  • Weapon Orientation
  • Gaming Systems
  • Robotics Navigation
  • Head Tracking
  • Motion Capture
  • Antenna/Platform Stabilization
  • Virtual and Augmented Reality
  • Training and Simulation
  • Unmanned Vehicles Navigation
  • Pedestrain Navigation
  • Movement Science
  • Artificial Horizon
  • Autopilot Systems
  • Human Input Devices
  • Inertial Aided GPS
  • Virtual Locomotion
  • Indoor Positioning
ProductsRange (Heading/Attitude)Sensor range (Accelerometer/Gyro/Magnetometers)Angular resolutionSensor resolutionSupply Voltage
AHRS-I0-360°/ ±90°, ±180°±2g, ±6g / ±250°,500°,1000°,2000° per sec/ ±1.6 gauss0.01°0.005mg/ 10° per hr/ 0.2nT+5.5V to +6.5V
optoAHRS-II0-360°/ 0-360°0.05°0.005mg/ 10° per hr/ 0.2nT12-26 Vdc
AHRS-II-B0-360°/ ±90°, ±180°±10g/ ±450° per sec/ ±2 gauss/ 300-1100hPa (Pressure)0.01°0.02mg/ 1° per hr/ 4nT9-36 Vdc
AHRS-II-E0-360°/ ±90°, ±180°±8g/ ±450° per sec/ ±2 gauss 300-1100hPa (Pressure)0.01°0.005mg/ 1° per hr/ 4nT9-36 Vdc
AHRS-II-P0-360°/ ±90°, ±180°±8g/ ±450° per sec/ ±1.6 gauss 300-1100hPa (Pressure)0.01°0.005mg/ 1° per hr/ 0.2nT9-36 Vdc
Those Attitude and Heading Reference Systems consist of microelectromechanical systems (MEMS) gyroscopes, accelerometers and magnetometers on all three axes.
    • – Commercial
    • – Military
For more information, CONTACT US now with your application details.
